Main Parameters
Body type Liftback
Drive type Front
Body model DAA-ZE2
Number of doors 5
Release period November 2011 - 2013
Transmission type CVT
Steering wheel position Right
Winter equipment
Hybrid
Trim name 1.3 L
Engine capacity, cc 1339
Ground clearance, mm 145
Engine
Supercharger
Engine type In-line, 4-cylinder
Engine model LDA
Start-stop system
Fuel type Regular gasoline (AI-92, AI-95)
Environmental type Reduction of toxic emissions by 75% according to the 2005 standard
Variable cylinder volume mechanism
Max power, hp (kW) at rpm 88 (65) / 5800
Max torque, N*m (kg*m) at rpm 121 (12) / 4500
Electric Drive
Hybrid type Parallel
Electric motor: power, kW 10
Electric motor: torque, Nm 78
Hybrid system: combined power, hp 99
Gearbox
Gear selector position On the floor
Fuel Consumption
Fuel consumption norm Compliance with the 2010 fuel consumption standard +25%
Fuel consumption in 10/15 mode, l/100km 3.2
Combined fuel consumption, l/100 km 3,2
Body Dimensions
Body dimensions (L x W x H), mm 4390 x 1695 x 1425
Weight & Loads
Weight, kg 1190
Power-to-weight ratio, kg/hp 13.52
Suspension
4WS
Rear suspension Semi-independent, torsion beam
Front suspension Independent, MacPherson strut type
Lowered suspension
Sport suspension
Air suspension
LSD differential
Cross-axis lock
Brakes
Rear brakes Drum
Front brakes Disc ventilated
Steering
Hydraulic power steering
Electric power steering
Steering type Rack and pinion
Change of steering ratio (VGS/VGRS)
Tires
Runflat tires
Rear wheels 185/6 R5 R15
Front wheels 185/6 R5 R15
Doors
Door closer
Electric trunk lid
Sliding doors on both sides
Sliding door on one side
Sliding doors with electric actuation on both sides
Sliding door with electric actuation on one side
Roof
Roof hatch
Targa
Hardtop
Large roof hatch
T-shaped roof
Seats
Ottoman
Front passenger seat
Second row of seats Folds in 60/40 ratio
Sport seats
Removable seats
Seat position memory
Passage between the second row seats
Electrically heated rear seats
Electric front seats
Heated front seats option
Fully folding seats
Driver's seat height adjustment
Electric third row seat actuator
Electrically powered driver's seat
Passage between the driver and passenger seats
Audio Systems
Radio option
CD player option
MD player
DVD audio option
Speakers
Cassette player
Built-in memory storage option
Lights & Optics
Xenon headlights
Headlight washers
Tail lamps
Front fog lights
Additional Equipment
Underfloor storage in the trunk
Automatic toll payment system (ETC) option
Wheel Rims
Alloy wheels option
Magnesium alloy wheels
Interior Dimensions
Number of seats 5
Number of seat rows 2
Salon dimensions (W x H x L), mm 1935 x 1430 x 1150
Side Mirrors
Side mirrors with auto-positioning
Interior Design
Leather seats option
Water-repellent upholstery
Antibacterial treatment
Climate Control
Air conditioning
Humidifier
Interior filter
Air cleaner
Air cleaner
Electrical Package
Remote key
Electric window lifters
Child Safety
ISOFIX attachment
Built-in child seat
Airbags
Curtain airbags option
Side airbag option
Knee airbag
Driver's airbag
Front passenger airbag
Steering Wheel & Dashboard
Engine start button
Electrically heated steering wheel
Multimedia & Navigation
Navigation system option
Full-color LCD monitor option
Parking assistance system option
Traffic warning system option
Built-in monitor for rear passengers
Additional navigation equipment
Additional Interior Equipment
Exterior Extras
Roof rails
Rear spoiler
Front spoiler
Chassis Dimensions
Wheelbase, mm 2550
Rear track width, mm 1470
Front track width, mm 1480
Minimum turning radius, m 5
Glass & Visibility
Rain sensor
Factory tinting
UV-protective glazing
Active Safety & Driver Assist
AYC
SH-4WD
Parking sensors
Cruise control
Rear view camera option
Side view cameras
Front view camera
Night vision system
Automatic parking (IPA)
Adaptive Cruise Control (ACCS)
Anti-lock Braking System (ABS)
Traction Control System (TCS)
Electronic Stability Program (ESP)
Downhill Assist Control (DAC)
Brake Assist System (BAS)
Adaptive front-lighting system (AFS)
Lane Departure Prevention (LKA)
Collision avoidance system with automatic braking function
