Main Parameters
Body type Sedan
Drive type Front
Body model CV3
Number of doors 4
Release period 2017 - 2020
Transmission type CVT
Hybrid
Trim name 2.0 e-CVT Hybrid
Engine capacity, cc 1993
Acceleration 0-100 km/h, s 7.8
Manufacturer's warranty 3 years or 36,000 miles
Max speed, km/h 241
Ground clearance, mm 147
Engine
Supercharger
Engine type In-line, 4-cylinder
Piston stroke, mm 96.7
Compression ratio 13.5
Engine model LFA1
Start-stop system
Cylinder diameter, mm 81
Fuel type Regular gasoline (AI-92, AI-95)
Additional engine information DOHC, i-VTEC
Valves per cylinder 4
Compliance with ecological standards (LEV) LEV3-SULEV30
Max power, hp (kW) at rpm 143 (105) / 6200
Max torque, N*m (kg*m) at rpm 175 (18) / 4000
Electric Drive
Hybrid type Parallel
Battery capacity, kWh 1.3
Electric motor: power, kW 135
Additional information about the electrical installation 1 electric motor installed (front 135 kW)
Electric motor: torque, Nm 232
Hybrid system: combined power, hp 233
Gearbox
Main gear 3.421
Paddle shifters
Fuel Consumption
Extra-urban fuel consumption, l/100 km 5
Urban fuel consumption, l/100 km 4.9
Combined fuel consumption, l/100 km 4,9
Body Dimensions
Body dimensions (L x W x H), mm 4882 x 1862 x 1450
Weight & Loads
Weight, kg 1515
Power-to-weight ratio, kg/hp 10.59
Suspension
Rear suspension Independent, multi-link
Front suspension Independent, MacPherson strut type
Rear stabilizer
Sport suspension option
Front stabilizer
Brakes
Rear brakes Disc ventilated
Front brakes Disc ventilated
Parking brake Electronic
Steering
Hydraulic power steering
Electric power steering
Steering type Rack and pinion
Steering wheel ratio 11.8
Number of turns of the steering wheel from the lock to the lock 2.3
Change of steering ratio (VGS/VGRS)
Tires
Rear wheels 225/50 R17
Front wheels 225/50 R17
Doors
Electric trunk lid
Door handles in body color
Volumes
Trunk volume, l 473
Fuel tank volume, l 48
Seats
Second row of seats Folds in 60/40 ratio
Front seat ventilation
Seat position memory
Front seat adjustment 8-way driver's seat, 4-way front passenger seat
Electrically heated rear seats
Electric front seats
Rear center armrest
Heated front seats
Pockets on front seat backs
Front center armrest
Driver's seat height adjustment
Headrests in front seats
Electrically powered driver's seat
Audio Systems
Hands free
Radio
MP3 support
Additional audio equipment 4 speakers, USB
Lights & Optics
Light sensor
LED headlights
LED headlamps
LED rear lights
Additional stop light
Tail lamps
LED fog lights
Additional Equipment
Interior lighting on entry
Side mirrors
Auto-dimming rearview mirror
Additional
Aerodynamic drag coefficient, cW 0.28
Wheel Rims
Rear rims 17X7.5J
Front rims 17X7.5J
Alloy wheels
Body color
Metallic body paint option
Interior Dimensions
Number of seats 5
Number of seat rows 2
Side Mirrors
Heated mirrors
Side mirrors in body color
Electric side mirrors
Side mirrors with auto-positioning
Side mirrors with turn signal indicators
Interior Design
Leather interior
Cloth interior
Climate Control
Air conditioning
Climate control
Interior filter
Separate climate control 2 zones
Electrical Package
Central locking
Keyless access
Remote key
Rear electric windows
Front electric windows
Airbags
Curtain airbags
Side airbag
Knee airbag
Driver's airbag
Front passenger airbag
Passenger airbag with deactivation function
Passive Safety
Seat belt anchor
Tensioner
Three-point seatbelt
Steering Wheel & Dashboard
Tachometer
On-board computer
Projection display
Engine start button
Temperature sensor
Adjustable steering column
Vertical steering column
Leather-wrapped steering wheel
Steering wheel audio control
Telescopic steering column
Color multi-functional display
Multimedia & Navigation
Compass
Navigation system
Full-color LCD monitor
Additional Interior Equipment
Smoker's package option
Electrical outlet
Additional sound insulation
Qi wireless charging
Chassis Dimensions
Wheelbase, mm 2830
Rear track width, mm 1610
Front track width, mm 1600
Minimum turning radius, m 5.8
Glass & Visibility
Rain sensor
Heated rear window
Top part of the front window tinting
Active Safety & Driver Assist
Cruise control
Rear parking sensors
Front parking sensors
Rear view camera
Adaptive Cruise Control (ACCS)
Anti-lock Braking System (ABS)
Auto-lock doors when driving
Traction Control System (TCS)
Mode switch
Blind spot monitoring system
Tire pressure monitoring system
Electronic Stability Program (ESP)
High beam control system
Brake Assist System (BAS)
Hill-start Assist Control (HAC)
Electronic Brakeforce Distribution (EBD)
Lane Departure Prevention (LKA)
Collision avoidance system with automatic braking function
